In stock
INVERTEK
INVERTEK
Invertek · ODP 2
Invertek Optidrive P2 ODP-2-42150-3HF4A-MN – 15Hp 200~240V 3Ph IP66/NEMA4X Indoor/Outdoor
Invertek Optidrive P2 – Model ODP-2-42150-3HF4A-MN Power: 15Hp / 11kW Output Current: 46A Input Voltage: 200~240V 3Ph ...
Power
15.0 HP / 11.0 kW
Check datasheet
Voltage
Three Phase 200-240V
Input class
Enclosure
IP66/NEMA4X Indoor/Outdoor
Model dependent
Authorized distributor. Genuine Invertek product, full manufacturer warranty.
Free quick tech support. Sizing and parameter help during business hours.
Limited warranty. Manufacturing defects, components, and firmware coverage as applicable.
ALL SPECIFICATIONS
Specifications, grouped by category
Power & output
Output power (Hp)
15.0
Output power (kW)
11.0
Output current (A)
46.0
Electrical input
Input voltage
Three Phase 200-240V
Output voltage
Three Phase 200-240V
Internal EMC filter
✓
Enclosure & dimensions
Enclosure rating
IP66/NEMA4X Indoor/Outdoor
Frame size
4
Dimensions (in)
14.2 x 9.5 x 10.7
Weight (lb)
20.9
Control & safety
Safe Torque Off
✓
Communications
Modbus RTU/CANopen
Keypad / display
TFT Keypad
Built-in protection
Brake Transistor
Certifications & approvals
Approvals
UL, cUL, EAC, RCM
